商品概要
JAN:4539770112928
4ポジション
60mmBACK/40mmUP
60mmBACK/50mmUP
70mmBACK/40mmUP
70mmBACK/50mmUP
・ブラックアルマイト仕上げ
・チェンジ&ブレーキペダル可動部ベアリング仕様
・正チェンジのみ
・STDマスター使用可能
■DAEGモデルに装着時の注意点
・STDマフラーと同時装着の場合、70バック/40アップのポジションが使用できません。
・ポジションによってはブレーキホースの取回しがきつくなります。フィッティングの取り回しを変更してください。
・STDより30mm程度長いブレーキホースへの交換を推奨いたします。
4 position:
60mm back/40mm up
60mm back/50mm up
70mm back/40mm up
70mm back/50mm up
・Black anodized finish
・Change and brake pedal with movable bearing
・Only compatible with regular (forward) shifting
・Compatible with standard master cylinder
■Notes for installation on DAEG model:
If installing with the standard muffler, the 70mm back/40mm up position cannot be used.
Depending on the position, the routing of the brake hose may become tight.
Please adjust the fittings accordingly.
It is recommended to replace the brake hose with one that is approximately 30mm longer than the standard length.
商品説明
新設計の4ポジションバックステップキットは、深めの凸凹がバーエンドまで削り出された新型ステップバーを採用。
従来品と比べペダル可動部にベアリングが組み込まれ、精度の高いシフト&ブレーキフィーリングと滑り難く踏込みの安定感を向上させたバックステップに仕上がっています。
The newly designed 4-position backstep kit features a redesigned step bar with deeper grooves that are machined all the way to the bar end.
Compared to previous models, this kit incorporates bearings in the pedal movement area, resulting in improved precision for shifting and braking, as well as enhanced stability and reduced slippage during pedal operation.
The overall result is a backstep kit that offers a high level of accuracy and a secure feeling when engaging with the shift and brake pedals.
従来品と比べペダル可動部にベアリングが組み込まれ、精度の高いシフト&ブレーキフィーリングと滑り難く踏込みの安定感を向上させたバックステップに仕上がっています。
The newly designed 4-position backstep kit features a redesigned step bar with deeper grooves that are machined all the way to the bar end.
Compared to previous models, this kit incorporates bearings in the pedal movement area, resulting in improved precision for shifting and braking, as well as enhanced stability and reduced slippage during pedal operation.
The overall result is a backstep kit that offers a high level of accuracy and a secure feeling when engaging with the shift and brake pedals.
